Items |
Parameters |
|
|
Operation System |
Embedded Linux |
|
|
System Language |
Chinese, English, other (customizable) |
|
|
Video Compression Format |
H.264 compression mode |
|
|
OSD |
Character overlay function, support time and date, Vehicle ID and other information image overlay |
|
|
GUI |
Graphical OSD interface |
The system parameters can be set via an external display, remote control operation |
|
Video and recording system |
Video input |
4 or 8 video input, avatar header, 1.0Vp-p, 75Ω |
|
Video output |
1-way composite video output, avatar header, 1.0Vp-p, 75Ω. |
|
|
Preview function |
Single or multi-screen splicing preview, support manual / event trigger full-screen display function |
|
|
Video Resolution |
Four-way machine support 720P / D1 / HD1 / CIF optional, maximum support 4-way 720P; Octal support D1 / HD1 / CIF optional, maximum support 8 D1. |
|
|
Video Quality |
1 to 4 video can be equipped with the best 4, the lowest 4 |
|
|
Recording rate |
PAL: 100 frames / s, CCIR625 line, 50 field NTSC: 120 frames / s, CCIR525 line, 60 fields; CIF: 256Kbps ~ 1.5Mbps, 4 quality optional HD1: 600Kbps ~ 2.5Mbps, 4 quality optional D1: 800Kbps ~ 3Mbps, 4 quality optional 720P: 800Kbps ~ 4Mbps, 4 quality optional |
|
|
Video Mode |
The default automatic video, support for ignition video, manual video, alarm video and so on |
|
|
Audio |
Audio input |
4 or 8, the air head interface |
|
Audio output |
1 road, air head interface |
|
|
Compression |
G.726 compression format, rate 40KB / s |
|
|
Alarm input |
4 alarm input, with alarm linkage function |
|
|
Alarm Output |
1 switch output |
|
|
Positioning |
Supports built-in GPS / BD modules |
|
|
Sensor |
Supports G-SENSOR acceleration sensor |
|
|
Video storage
|
SD card |
1 ~ 2 large capacity SD card video, maximum support 128G, circular video, data automatically cover |
|
Upgrade method |
Support SD card upgrade |
|
|
file format |
H.264 |
|
|
File system |
Unique preloaded professional file system |
|
|
Video playback
|
Video search |
You can search video files by recording time, recording mode, etc. |
|
Playback
|
Support multi-channel synchronization playback, pause, fast forward, rewind |
|
|
Support 2, 4, 8, 16, speed fast forward or backward |
||
|
Power and power consumption
|
Power management |
Adaptive wide power input, with overload, overvoltage, undervoltage, short circuit, reverse connection and other protection functions; Support the timer switch, delay shutdown function. |
|
Input voltage |
DC:+10V ~ +36V |
|
|
The output voltage |
+12V@2A， |
|
|
Power consumption |
Normal working condition <5W |
|
|
Power & consumption |
Working current |
Around 12V=350MA |
|
Standby current |
Around 12V=40MA左右 |
|
|
working environment
|
temperature |
-20℃ to +70℃ |
|
humidity |
20% to 80% |
|
|
|
Password access |
User password, administrator password two levels of management |
|
Safety management |
000000 |
User |
|
|
111111 |
Admin |
